DESCRIPTION

WORLD'S BEST (WB) SNOW BELT

COMPOUND

• Third Generation heavy-duty, high-twist Kevlar Fiber cord for HIGH HORSEPOWER TENSILE LOAD requirements, making it the strongest belt on the market.
• Manufacturing, quality control certifications ‚Äî ISO-14001, ISO-9001, and IATF-16949
• This belt is for the rider and racer that is looking for the latest in technology and proven performance.
• Highest shock load rating to date being able to withstand the power of the 400hp machines.



CORD

• Kevlar Fiber cord, versus polyester, wraps over bottom cogs for increased bottom cog strength.
• Precision ground sidewall angle (SCUFFING). Therefore, smooth engagement and increased power transfer and lower operating belt temperature.
• Increased cord pop-out resistance.



TOP COG

• Increased top cog pressure load design that increases sidewall rigidity, prevents top cog bowing, but still allows for increased rotational flexibility.
• Bottom cog uses HIGH MODULUS RUBBER COMPOUND (BZX1). For this reason, better heat resistance and heat dissipation.
• Bottom cog is impregnated with short Kevlar Fibers. As a result, is has better belt-to-sheave adhesion and reduced overall belt temperature.
• Latest bottom cog design for greater rotational efficiency at full shift.



EXTREME (EX) SNOW BELT

COMPOUND

• High-temperature, heat-resistant with directionally-oriented fibers.
• Will handle the heat / friction for maximum power transfer through clutches.
• Engineered to keep maximum under-cord stiffness across the belt while giving stable cord construction base and allowing the belt to flex for efficiency and cool running temperatures.
• Helps retain cord line position ‚Äî won‚Äôt expand or bulge out under top cog.



CORD

• Next-generation, ultra-strong Aramid fiber cord.
• Can handle / carry more than 10,000 pounds of tension without stretching or breaking.
• Stronger than OEM and aftermarket drive belts.



TOP COG

• Next generation cog design.
• Above-cord strength, flexibility, and heat resistance.
• A must for today‚Äôs high-horsepower / high-torque motor / clutch applications.

FITMENT:

Replaces OEM #'s 417300531 / 417300391 / 417300383 / 417300571 / 417300534 / 417300425 / 417300166 / 417300558
